Tipper Dump Truck SINOTRUK LHD 371HP 10 wheels 30 - 40tons for Mining Industry
Description:
Tipper Dump Truck SINOTRUK LHD 371HP 10 wheels 30 - 40tons for Mining Industry
HOKA brand is the Leader of Heavy Duty Truck Industry Driving King On The Road.
High Quality , More Lighter . High Level Comfortable:Cabin 4 point full -floating air
suspension ,adjustable steering wheel with various heightsand angles.air suspension seat,
Cruise Constant Speed System,MINI Player .electrical control glass and mirror,ATM
Gearbox ,bunk with AC.
The standard 400 liter Aluminum Alloy tank. Also optional 600 liter Aluminum Alloy large tank. 600 liters fuel tank (with large unilateral combined pedal) high strength lightweight materials for the new international standard of heavy truck, the A7 tractor has more than 1500 kilometers of super endurance.
Cab interior
Warm interiors make driving more comfortable environment inside the room. The whole wraparound dashboard, all the joystick layout, at your fingertips.
Primer and topcoat coating in Chinese's independent research and development of the new paint line, advanced equipment and high-quality paint makes the vehicle paint life, cleanliness, brightness, corrosion resistance and adhesion have reached or exceeded the international level.
Specifications:
| Tipper Dump Truck SINOTRUK LHD 371HP 10 wheels 30 - 40tons for Mining Industry |
| Model | ZZ3257N3647B1 |
| Drive Type | 6×4 |
| Engine | | WD615.47 , 371HP( Euro II) | | 6 cylinder in-line with water cooling, turbo-charging & inter-cooling,4 stroke electronic fuel injection diesel engine | | Displacement : 9.726L | |
| Cabin | A7-W lengthened cab(with one sleeper, air-conditioner and new-style seat) |
| Transmission | HW15710(10 forwards & 2 reverses) |
| Front Axle | 1×HF9 ( 9 Tons) |
| Driving Axle | HC16, 16Tons |
| Steering | ZF8118 hydraulic steering with power assistance. |
| Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance |
| Rim/ Tire | 11.00R20,12.00R20,12.00R24 Radial tire |
| Wheel base | 3600+1350(mm) |
| Overall dimension | 8375×2496×3450(mm) |
| Cargo body | 5600×2300×1500(mm),Bottom:8mm, Side:6mm |
| The curb weight | 12300(Kg) |
| Gross weight | 25000 kg |
| Max. speed | 75km/h |
| Color | White, red, green, golden and so on.
|
Applications:
working for Mining industry, Construction business, docks, to transport soil, sand, stones and so on.
Competitive Advantage:
1)fast delivery time, we can arange production according to your needs exactly and
quickly
2) professional import and export dealing precedure, make customs clearance more high efficiency
3)competive price, cost-effective
4)low fuel consumption
5) strong enough engine
6)with all kinds of truck model, which can fulfil your requirement
7)the key parts adopt the world's top technology products
8)based on strong technical support and top level technology make the trucks with high
quality and more reliable
9)quick and efficient spare parts supply bring you more convenient
10)Optimized cargo body structure,light weight,high rigidity,large loading capacity
11)Using the high strength steel,it has long service life
12)Optimized the sealing structure has the better sealing effect.
13)Multiple box structures and device selections
14)The intelligent hydraulic control system helps to avoid error operation, it has higher safety and
running efficiency.
